This travel trailer solar system is designed specifically for RVs and tiny homes, featuring flexible solar panels that adapt seamlessly to your space. Whether you're hitting the road or setting up a stationary off-grid retreat, this kit has you covered, providing reliable, renewable energy to power your adventures.
Offering the best value on the market, this system ships directly from California, ensuring fast delivery so you can start your off-grid journey without delay.
| Rated Output Power | 10000VA/10000W |
| Nominal Output Voltage | 120VAC(P-N)/208VAC(P-P)/240VAC(P-P) |
| Output Voltage Range | 105.5-132VAC per phase |
| Nominal Output Current | 41.5A per phase |
| Maximum PV Input Power | 12000W |
| Maximum DC Voltage | 600VDC |
| Start-up Voltage/Initial Feeding Voltage | 125VDC/160VDC |
| MPP Voltage Range | 120VDC-550VDC |
| MPPT Trackers/Max Input Current | 2/18A |
| Battery DC Voltage Range | 40-62VDC |
| Maximum Solar Charging Current | 200A |
| Maximum AC Charging Current | 200A |
| Maximum Charging Current | 200A |
| Operating Temperature Range | -25°C to 60°C (>45°C derating) |
| Protection Degree | IP65 |
| Communication Port | RS232, RS485, Wi-Fi, USB |
| Dimensions (DxWxH) (mm) | 215.5x575x715 |
| Net Weight | 45 kg / 99.2 lb |
| PARALLEL CAPABILITY | Yes, 6 units |
| Nominal Voltage | 51.2V |
| Nominal Capacity (at 0.5C, 77°F) | 100Ah |
| Minimum Capacity (at 0.5C, 77°F) | 99.5Ah |
| Nominal Capacity | 5120Wh |
| Charging Voltage | 57.6V |
| Discharging Cutoff Voltage | 44.8V |
| Maximum Charging Current | 100A |
| Continuous Charge Current | 100A |
| Maximum Discharge Current | 100A |
| Battery Dimensions | 17.7″L x 17.8″W x 5.2″H |
| Weight | 99.2 lb |
| Operation Voltage | 43.2~58.4V |
| Maximum Charging Current | 100A |
| Maximum Discharging Current | 100A |
| Maximum Charge Voltage (CC/CV) | 57.6V |
| Overcharge Protection Voltage | 58.4V |
| Overcharge Protection Release Voltage | 54V |
| Over Discharge Protection Voltage | 43.2V |
| Over Discharge Protection Release Voltage | 47.2V |
| Over Discharge Primary Charge Overcurrent Protection Value | 110A |
| First Stage Charge Over Current Delay | 1s |
| Primary Discharge Overcurrent Protection Value | 110A |
| Primary Discharge Overcurrent Protection Delay | 1s |
| Secondary Discharge Overcurrent Protection Value | 150A |
| Secondary Discharge Overcurrent Protection Delay | 500ms |
| Charge Temperature | 0.1C@(0℃~10℃); 0.2C@(10℃~20℃); 0.5C@(20℃~25℃); 1C@(25℃~45℃); 0.3C@(45℃~55℃); 0.2C@(55℃~60℃) |
| Discharge Temperature | -20℃~65℃ (max cell surface temp 65℃) |
| Storage Temperature | -20℃~45℃ 90%RH Max(1 month); 0℃~35℃ 90RH Max(6 Months) |
| Recommended Storage Temperature | 0℃~35℃ 85%RH Max (reduced battery life if stored in high temp) |
| Communication Ports | RS485/RS232/CAN |
| Warranty | 10 Years Manufacturer Defect |
12000 Watt 120/240V Hybrid Off-grid Solar Inverter User Manual
12000 Watt 120/240V Hybrid Off-grid Solar Inverter Specification
ALPHA 5 PRO | 51.2V 100Ah Server Rack Lithium Iron Phosphate Battery Specification
ALPHA 5 PRO | 51.2V 100Ah Server Rack Lithium Iron Phosphate Battery User Manual
