Easy Install
The Sol-Ark INVERTER comes with everything you need to install it. Nicely packaged for added efficiency.
Fleet Management
With Sol-Ark’s remote access features and app you are never out of touch to quickly repair or adjust any system without being on site.
Battery Agnostic
Sol-Ark inverters also do not have expensive battery restrictions like other solar inverters do, and can be used with a wide variety of 48V battery chemistries, from lead to lithium.
Warranty and Reliability
Comes with our award winning iron clad warranty and our 7 day a week live Engineering Support to assist you in all your needs.
Max. Allowed PV Power (STC) | 19,500W |
Nominal Voltage Range | 175 - 425V |
Startup Voltage | 125V |
Max. Input Voltage | 500V |
Max. Input Current per MPPT | 26A (self-limiting) |
No. of MPP Trackers | 3 |
No. of PV Strings per MPPT | 2 |
Nominal AC Voltage (L-L) | 120/240V, 120/208V, 220V |
Grid Frequency | 50 / 60Hz |
Real Power, max continuous | 15,000W |
Max Output Current | 62.5A |
Real Power, max continuous (batteries only) | 12,000W (50A @ 240V) |
Peak Apparent Power | 24,000VA |
Peak Apparent Power | 30,000VA |
Max Output Fault Current (5s) | 94A with PV, 75A (batteries only) |
Max Output Fault Current (100ms) | 120A |
Max. Grid Passthrough Current | 200A |
Power Factor Output Range | +/- 0.8 adjustable |
Backup Transfer Time | 5ms |
CEC Efficiency | 96.5% |
Max Efficiency | 97.5% |
Design (DC to AC) | Transformerless DC |
Stackable | Up to 12 in parallel |
Battery Technologies | Lithium / Lead Acid |
Nominal DC Voltage | 48V |
Operating Voltage Range | 43 - 63V |
Capacity | 50 — 9900Ah |
Max. Battery Charge / Discharge Current | 275A |
Charging Controller | 3-Stage with Equalization |
Grid to Battery Charging Efficiency | 96.0% |
External Temperature Sensor | Included |
Current Shunt for Accurate % SOC | Integrated |
Automatic Generator Start | Integrated |
Communication to Lithium | CANBus & RS485 |
Dimensions (H x W x D) | 807 x 494 x 306 mm / 31.8 x 19.4 x 12 in |
Weight | 61.2 Kg / 135 lb. |
Enclosure | IP65 / NEMA 3R |
Ambient Temperature | -25~60°C, > 45°C Derating |
Noise | < 30 dB |
Idle consumption - No Load | 60W |
Wi-Fi & LAN Communication | Included |
Warranty | 10 Years |
Electronics Certified Safety | by SGS Labs to NEC & UL Specs - NEC 690.4B & NEC 705.4/6 Yes |
Grid Sell Back | UL1741-2010/2018, IEEE1547a 2003/2014, FCC 15 Class B, UL1741SB, CA Rule 21, HECO Rule 14H Yes |
PV DC Disconnect Switch | Integrated |
Ground Fault Detection | Integrated |
PV Rapid Shutdown Control | Integrated |
PV Arc Fault Detection | Integrated |
PV Input Lightning Protection | Integrated |
PV String Input Reverse Polarity Protection | Integrated |
AC Output Breaker | 200A Integrated |
Battery Breaker / Disconnect | 200A x 2 Integrated |
Surge Protection | DC Type II / AC Type II |
Sol-Ark 15K EMP Hybrid/Off Grid Solar Inverter Datasheet
